Dahua Alarm 8 Zone Input expander module
- 8-channel alarm inputs
- 2-channel alarm outputs
- Address setting with DIP switch
- EOLR configuration (2K7, 4K7, and 6K8)
- Alarm output switch between NO (Normally Open) and NC (Normally Closed) with jumper
- Remote update by client software
KSh 8,700.00
Description
Technical Specification
Port
Alarm Output 2
Alarm Iutput 8
RS-485 1, connected to a maximum of 300 m ( 984.25 ft )
cable typed RVV2*1.5
Function
Device Address 0–15( ARC9 series, ARC2 series )
1–8( ARC3008 )
Zone Terminations NC, NO, 1EOL, 2EOL, 3EOL, INERTIAL(ARC3008), and
IMPULSE(ARC3008)
EOLR 2K7, 4K7, and 6K8
Alarm Output Mode Switch between NO and NC with jumper
Output Capacity 30 VDC/500 mA
Update Remote update by client software
General
Power Supply 12 VDC
Power Consumption 1.2 W
Operating Temperature–10°C to +55°C (+ 14°F to + 131°F)
Operating Humidity 10%–90% ( RH )
Product Dimensions 90.0 mm × 62.0 mm × 12.6 mm ( 3.54″ × 2.44″ × 0.5″
) ( L × W × H )
Net Weight ≤1 kg ( 2.20 lb
